The Reolink Elite Floodlight WiFi was the first floodlight camera from Reolink designed to be wired directly into your mains, similar to traditional floodlights and most competing smart video floodlights. Reolink announced the TrackFlex Floodlight WiFi back in September, and I have been reviewing it for the past few weeks. If you are familiar with Reolink, you will realize this combines the tech from the aforementioned Elite Floodlight but swaps out the 180-degree dual lens design for the dual lens design of the Reolink Trackmix where you have an 8MP 4K wide-angle lens, then a second 4MP 2K zoom lens with a 6x hybrid zoom with pan and tilt functionality which can track objects providing 360 degree coverage.

Related Reviews

Specification:

• Image Sensor: 1/3″ + 1/2.8″ CMOS Sensors
• Resolution: 3840 × 2160 (8MP) @ 20fps, 1920 × 1080 (2MP) @ 20fps
• Lens: f=2.8mm fixed, F=1.6, f=8mm fixed, F=1.6
• Field of View: Wide Angle: Horizontal: 104°, Vertical: 60°, Tracking: Horizontal: 38°, Vertical: 21°
• Zoom: 6x hybrid zoom
• Infrared Night Vision: Up to 30 meters (100ft); LED: 2pcs/850nm
• Colour Night Vision: With Floodlights: 3000 Lumens / 3000K–6000K
• Frame Rate: Main Stream: 2fps – 20fps (default: 20fps), Sub Stream: 4fps – 20fps (default: 20fps)
• Code Rate: Main: 4096Kbps; Sub: 1024Kbps, Wide Angle: 2048–8192Kbps (default: 5120Kbps)
• Audio: Two-way audio
• Siren: 110dB
• Power Supply: AC 100V–240V, 50~60Hz; DC 5V–2A (set up only)
• Power Port: DC power port
• Reset Button: Yes
• microSD Card Slot: Supports up to 512GB microSD card
• PT Angle (Max.): Pan: 355°, Tilt: 50°
• Pan/Tilt Speed: Pan: 90°/s; Tilt: 60°/s (adjustable)
• Preset Points: 1 guard position + up to 64 presets
• Patrol: No
• Auto-Tracking: Yes
• Wireless Standard: IEEE 802.11 ac/ax/a/b/g/n
• Operating Frequency: 2.4GHz/5GHz
• Wireless Security: WPA/WPA2/WPA3
• Browser Supported: Edge, Chrome, Firefox, Safari
• OS Supported: Windows, macOS, iOS, Android
• Protocols/Standards: HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
• User Access: 20 users (1x admin, 19x user max), 12 streams (2 main, 10 sub)
• Smart Alarm: Detection for human, vehicle, animal
• Record Modes: Motion-triggered (default), scheduled, 24/7
• Time Lapse: Yes
• Smart Home Compatibility: Google Assistant
• AI Video Search: Yes
• Operating Temperature: -10°C – 55°C
• Operating Humidity: 10% – 90%
• Weatherproof: IP66
• Dimensions: 283 × 184 × 199 mm
• Weight: 1.228 kg
• Warranty: 2 years, limited

  Features:

  Camera and Visuals:
  The device is equipped with a dual-lens system. One lens provides a wide-angle view in 4K resolution, while a second telephoto lens enables a 6x hybrid zoom for closer inspection of distant objects. This setup allows for a dual-view display on the Reolink app, showing both the wide overview and the zoomed-in image simultaneously. The camera is mounted on a pan and tilt mechanism, offering 360-degree horizontal coverage (355-degree pan) and 50-degree vertical tilt. This allows the user to monitor large areas without blind spots. For night-time operation, it has two modes. Infrared night vision provides black and white footage up to 30 meters away. Alternatively, color night vision is possible when the floodlights are active.

  AI Capabilities:
  On-device AI processing drives several of the camera’s smart functions without needing a subscription. The system can distinguish between people, vehicles, and animals, which helps to reduce false alerts. A notable function is the AI auto-tracking, where the camera automatically pans, tilts, and zooms to follow a detected subject as it moves. The camera also features a 270-degree out-of-view detection zone, using three PIR sensors. If motion is detected outside the camera’s current field of view, it will automatically turn to face and record the activity. The AI also powers a local video search tool. Users can type keywords, such as “white car” or “person carrying an umbrella”, into the app to find specific video clips from the local storage.

  Floodlight System:
  The integrated floodlights are a key part of the device. They can produce up to 3000 lumens of brightness with a range of approximately 12.2 meters. Users can adjust both the brightness level and the color temperature, from a warm 3000K to a cool 6000K, through the app. The lighting can be controlled with several smart modes. It can be set to a schedule, operate automatically from dusk-to-dawn, or activate only when motion is detected.

  Security and Storage:
  When the camera detects a person, vehicle, or animal, it can trigger a multi-layered alert system. This includes activating the floodlights, sounding a powerful 110dB siren, and playing a user-recorded five-second custom voice message. At the same time, a notification is sent to the user’s smartphone. Two-way audio is also supported via a built-in microphone and speaker. For video storage, the TrackFlex is not reliant on the cloud. It has a microSD card slot that supports cards up to 512GB for continuous local recording. The camera can also be integrated with a Reolink NVR (Network Video Recorder) or save footage to an FTP or NAS server.

  Connectivity and Build:
  The camera connects to your network using dual-band Wi-Fi 6 (2.4GHz and 5GHz), which offers faster data transfer and a more stable connection than older Wi-Fi standards. The connection is secured with the WPA3 encryption protocol. For smart home users, the device can be integrated with Google Assistant, allowing for voice commands to control the lights or view the live feed. The unit is designed for outdoor use with an IP66 weatherproof rating, protecting it from dust and water. It can be mounted on a wall or a ceiling, and the adjustable angles of the camera and lights provide flexibility for installation in different locations. The recommended mounting height is between 2.1 and 3 meters.

  Unboxing / Design:

  Installation:
  During the review, I mounted the camera in my usual location, which is just above my shed door. This placement is not ideal for this style of camera, as it is better suited at a higher position to maximize the zoom lens. Once the weather settles, I plan to use ladders to replace my Eufy Floodlight Camera E340.

  I connected the camera to the unterminated power lead that I previously used with the Elite WiFi.

  For most users, it is recommended to replace an existing outdoor light with electrical wiring already in place outdoors. If you need to drill into your wall, the installation will be more challenging.

  Assuming the wiring is already in place and there is no need to drill into brickwork, the installation process is relatively easy and similar to the Elite WiFi.

  There is a rear mounting plate with a cutout at the back for wiring over where the wires come out, or a small hole in the base with a rubber plug for running a cable through.

  Like many floodlight cameras, there is a convenient cable and hook system for hanging the camera while wiring it.

  The wiring process is simple, and in my case, I did not need to turn off the power at the mains. I used the included cable connectors, then mounted the camera onto the mount using two screws.

  Once the physical installation is complete, setting up the camera is the same as any other Reolink camera.

  The device pairs easily with the Reolink app, and the setup wizard guides users through the configuration step by step.

  You can choose to use the camera in standalone mode with a microSD card for storage or with the Reolink Homebase acting as an NVR.

  The Reolink mobile app provides full control over the TrackFlex Floodlight functions, with a user-friendly and well-organized layout. Accessing key options is simplified while still offering detailed configuration for advanced users.

  Motion detection is highly customizable with sensitivity profiles for human, vehicle, and animal detection. The AI engine reduces false positives from environmental motion. Zone-based configuration allows for targeted monitoring areas.

  Floodlight management provides manual and automated control with adjustable brightness and color temperature. Motion-triggered lighting is consistent and delay timers are configurable.

  Recording modes include motion-based, scheduled, continuous capture, and time-lapse options. Storage settings can be adjusted for local SD and NVR recording.

  Advanced detection features allow users to define virtual boundaries, intrusion zones, and loitering parameters within the app for added situational awareness.

  The motion detection features offer pan and tilt functionality, with options for auto tracking and digital tracking. Users can set preferences for tracking and adjust the horizontal tracking range. Out-of-view detection helps prevent the camera from missing objects. The monitor point setting allows users to specify the camera’s return position after motion recording. Brands such as Aqara and Eufy offer facial detection functionality, with better overall performance. Reolink stands out for its wide range of camera choices and the ability to record 24/7 to an NVR/Homebase.

  In terms of daytime video quality, the 4K 8MP lens of Reolink cameras provides excellent footage, capturing clear details of people, animals, or cars. The 2K 4MP sensor also offers good quality footage with more detailed zoomed-in images.

  For night and low-light video quality, Reolink cameras perform well, especially with the ColorX cameras that provide true color video in very low light conditions. The floodlights in the TrackFlex Floodlight WiFi camera switch to color mode when triggered, offering clear visibility of objects.

  The price of the Reolink TrackFlex Floodlight WiFi is $239.99, with UK pricing yet to be confirmed. Alternative options include the Elite Floodlight WiFi and the Reolink TrackMix PoE, both offering competitive pricing.

  Overall, the Reolink TrackFlex Floodlight WiFi is a great choice for surveillance needs, offering impressive video quality, customizable lighting, and subscription-free local storage. The mains-wired design makes it suitable for a wide range of users, allowing for easy installation and integration with existing floodlights.

  Review of a Feature-Rich Outdoor Light

  When it comes to the effectiveness of this outdoor light, it greatly relies on being installed in a high position to take advantage of its zoom feature. Despite this requirement, it remains an excellent choice for those seeking to enhance their existing outdoor lighting setup.

  Pros of the Outdoor Light:

  • Dual-lens 4K and 2K system with 6x hybrid zoom and auto-tracking
  • Bright 3000-lumen adjustable floodlights
  • Local microSD storage up to 512GB with optional NVR integration
  • Dual-band Wi-Fi 6 and WPA3 security
  • No subscription required for AI detection or smart features
